National Laboratory Standard Water Device Ultra Pure Water Filter System

National Laboratory Standard Water Device Ultra Pure Water Filter System National Laboratory Standard Water Device Ultra Pure Water Filter System National Laboratory Standard Water Device Ultra Pure Water Filter System National Laboratory Standard Water Device Ultra Pure Water Filter System National Laboratory Standard Water Device Ultra Pure Water Filter System National Laboratory Standard Water Device Ultra Pure Water Filter System
The system adopts multi-step purification process and ultraviolet sterilization and ultrafiltration technology. It is especially suitable for various physical and chemical testing, biochemical analysis, blood examination, microanalysis, and washing, HPLC, IC, GC, analytical experiments and other experimental projects.
  • ModelLD-WFUP Series
  • BrandLABOAO
  • PortAny port in China
  • PackagePlywood case package
Payment We also supports L/C、D/A、D/P、Western Union、MoneyGram、Discover payments for offline orders.


DESCRIPTION

The system adopts multi-step purification process and ultraviolet sterilization and ultrafiltration technology. It is especially suitable for various physical and chemical testing, biochemical analysis, blood examination, microanalysis, and washing, HPLC, IC, GC, analytical experiments and other experimental projects.

FEATURES

1.      Suitable for national water quality, the case adopts plastic spraying technology.

2.      All the filter elements in the system adopt mold opening and injection molding technology and are built in the chassis.

3.      Korean quick insert cartridges make replacement and maintance convenient.

4.      Complete separation of electrical appliances from waterways to avoid circuit failures caused by moisture and water leakage.

5.      Water quality online monitoring system, real-time measure water quality.

6.      Automatic RO film anti-scaling and washing program,automatic stop when tap water is cut off, automatic stop when water is cut off, automatic fill water in storage bucket, automatic stop when water is full.

7.      All pipelines have obtained NSF certification and have the function of upgrading water quality and quantity.

8.      Equipped with portable TDs pen,it can test TDs content, conductance and water temperature anytime and anywhere.

9.      Double electric water intake, two kinds of water quality, ready to use.

10.   Front and back door design,easy and fast filter element replacement, the whole process without using any tools, easy to complete the filter element replacement.

SPECIFICATIONS

Model

Standard;   Eliminating endotoxin; Low TOC; Synthesizing

LD-WFUP-10

LD-WFUP-F10

LD-WFUP-V10

LD-WFUP-VF10

LD-WFUP-20

LD-WFUP-F20

LD-WFUP-V20

LD-WFUP-VF20

LD-WFUP-30

LD-WFUP-F30

LD-WFUP-V30

LD-WFUP-VF30

Process

PP+ AC+ AC+ RO+   UP+ TF

PP+ AC+ AC+ RO+   UP+ UF+ TF

PP+ AC+ AC+ RO+   UP+ UV+ TF

PP+AC+AC+RO+UP+UV+UF+TF

Output(25

10L/H, 20L/H,   30L/H

Flow rate

Up to 2   liters/minute(with pressure tank)

Pure water   outlet

2: reverse   osmosls water, ultra-pure water

Ultra pure water   quality

Resistivity(25

18.2MΩ.cm

TOC

<10ppb

<10ppb

<3ppb

<3ppb

Bacteria

<0.1cfu/ml

Particle(>0.22μm

<1/ml

Endotoxin

N/A

<0.001Eu/ml

N/A

<0.001Eu/ml

RO water quality

Ion rejection   rate

95%-99%(new RO membrane)

Particles and   bacteria rejection rate

>99%

Feed water   requirements

Tap water,   temperature: 5-45, pressure:   0.15-0.4Mpa

Dimension and   weight

L*W*H:   41*27*50cm/Weight: about 23KG

Electrical   requirements

AC110-240V,   50/60Hz

Power

48-72W

Standard   configuration

Machine(including   1 set of cartridge)+12 liter pressure tank
